PT3600 Service Manual
21
Appendix 3 Structural Parts List
No. Part No. Name/Specifications Unit Qty.
1
7MHR-7123-01A-W9 Light Guide
PCS
1
2
7PLJ-7123-E01A LOGO
PCS
1
3
7MHP-7123-05A-W0 MIC/SPK Jack Cover
PCS
1
4
7MHP-7123-01A-W0 Front Casing
PCS
1
5
7GCB-360001-W0 Protective Net for Speaker
PCS
1
6
7GCB-070005 Dustproof Net for MIC
PCS
1
7
7SMF-020040M-SZYB-N1 M2.0*4.0 Pan Plus Machine Screw
PCS
8
8
7MHR-1727-09A-W3 MIC Waterproof
PCS
1
9
6PM7-7115-HMA PT3600 Main Board
PCS
1
10
7MHR-7042-05A-W0 PT568 Waterproof Gasket for Bracket
PCS
1
11
7MHP-7042-11A-W PT568 Battery Connector Assembly
PCS
1
12
7MHP-7123-07A-W0 MIC/SPK Jack Cover Plug
PCS
1
13
7SMF-020080M-MHHT-N1 M2*8 Thick Head Torx Machine Screw
PCS
2
14
7MDP-7126-02A-W0 Battery Bottom Casing
PCS
1
15
6BPM-063760-074130-A KB-31A Li-Poly Battery Pack
PCS
1
16
7MDP-7126-01A-W0 Battery Top Casing
PCS
1
17
7MJP-1740-02A-W0
(7ML-1826-01A-L0, 7MJS-1826-01A-W)
KBJ-05 Belt Clip Bracket (metal bracket)
PCS
1
18
7MJS-7128-01A-N KBJ-10 Belt Clip Bolt
PCS
1
19
7MJP-7128-01A-W0 Belt Clip
PCS
1
20
7MJS-3851-02A-W KBJ-01 Spring
PCS
1
21
7SMF-025050M-MHYB-Z2 M2.5*5 Pan Torx Black Zn-plated Machine Screw
PCS
2
22
7MHP-7123-08A-W0 Battery Latch
PCS
1
23
7MHS-1727-02A-N Battery Latch Spring
PCS
1
24
7MHP-7123-06A-W0 Top Cover
PCS
1
25
7MHR-7123-02A-W0 Main Waterproof
PCS
1
26
7MHL-7123-01A-WA Al Alloy Chassis
PCS
1
27
3CR7-SMA-50JFB-4 PT558 Antenna Connector
PCS
1
28
7SMF-020040M-SZYB-N1 M2.0*4.0 Pan Plus Machine Screw
PCS
2
29
7NRC-060100035-B1 Nut for Switches
PCS
2
30
7NRC-090136039-B1 Nut for Antenna
PCS
1
31
3SE3-RE08140AX-V01 Encoder Switch
PCS
1
32
2RW3-R08710NS-A103 Volume Potentiometer
PCS
1
33
7MHP-1010-15A-W 3208 PVC MIC Gasket
PCS
1
34
4SS7-4005-016-100B 7200 Gold-plated Speaker
PCS
1
35
7MHP-7123-04A-W0 PTT Button Cover
PCS
1
36
7MHR-7123-03A-W0 PTT Silica Gel Button
PCS
1
37
7MHP-7123-03A-W3 Encover Knob
PCS
1
38
7MHP-7123-02A-W0 Volume Knob
PCS
1
39
7MHR-7123-04A-W3 Emergency Button
PCS
1
To Next Page
