PT3600 Service Manual
20
101 2CC1-10-C0G500-220J Chip Multilayer Capacitor 1005,22P±5%,50V,C0G PCS 2 C303,C309
102 2CC1-10-C0G500-151J Chip Multilayer Capacitor 1005,150P±5%,50V,C0G PCS 2 C713,C732
103 2CC1-10-C0G500-120J Chip Multilayer Capacitor 1005,12P±5%,50V,C0G PCS 1 C575
104 2CC1-10-C0G500-101J Chip Multilayer Capacitor 1005,100P±5%,50V,C0G PCS 2 C552,C557
105 2CC1-10-C0G500-100D Chip Multilayer Capacitor 1005,10P±0.5P,50V,C0G PCS 2 C720,C721
106 1TT1-FMMT717TA Chip Triode FMMT717A,PNP,SOT23 PCS 1 Q622
107 1TT1-DTC144EUA Chip Triode DTC144EUA(26),SOT323 PCS 1 Q627
108 1TT1-DTC144EE Chip Triode Digital triode DTC144EE(26),SOT323 PCS 6 Q301,Q304,Q305,Q621,Q623,Q626
109 1TT1-DTA144EE Chip Triode Digital triode DTA144EE-SMD PCS 1 Q515
110 1TT1-2SC5108-Y Chip Triode 2SC5108-Y(MC),NPN PCS 1 Q506
111 1TT1-2SC3356-R24 Chip Triode 2SC3356-R24,SOT23,NPN PCS 1 Q507
112 1TF1-ST2302 Chip FET ST2302,SOT-23 PCS 2 Q632,Q634
113 1TF1-ST2301 Chip FET ST2301A,SOT-23 PCS 1 Q637
114 1TF1-RD07MUS2B Chip FET RD07MUS2B， ROHS PCS 1 Q501
115 1TF1-2SK3475 Chip FET 2SK3475,SOT-89(6200 silk-screen must be WB) PCS 1 Q502
116 1TF1-2SK1824 Chip FET 2SK1824(B1) PCS 3 Q508,Q624,Q625
117 1IS1-XC6204B332MR
Chip Voltage Regulator
IC
Voltage regulation integration 3.3V,SOT-23-5 PCS 2 Q636,Q639
118 1IS1-TDA2822 Chip Special IC TDA2822 PCS 1 U1
119 1IS1-RDA1846 Chip Special IC RDA1846, ROHS PCS 1 U8
120 1IS1-PST9140NR Chip Reset IC Reset IC,PST9140NR PCS 1 IC307
121 1IP1-R5F212A8SNFP Chip CPU IC
Blank, need to be programmed, MCU/R8C/2A,
R5F212A8SNFP, ROHS
PCS 1 U6
122 1IM1-W25X80AVSIG Chip Storage IC W25Q80BVSIG,SOIC,8Mbit, ROHS PCS 1 U4
123 1IM1-AT24C08BN-SH Chip Memory IC EEPROPM,AT24C08BN-SH(8-SOIC) PCS 1 IC305
124 1IL1-NJM2904V Chip Linear IC
Double operation amplification NJM2904V,
TSSOP-8
PCS 1 IC502
125 1DZ1-HZU5ALL
Chip Voltage Regulator
Diode
HZU5ALL,2012,5V PCS 1 DW501
126 1DS1-HVC131 Chip Switch Diode HVC131(P1),1608 PCS 4 D508,D511,D515,D517
127 1DS1-HSC277 Chip Switch Diode HSC277,1608 PCS 2 D403,D404
