Kirisun PT3600 Service Manual

PT3600 Service Manual
19
R325,R360,R368,R410,R548,R650,R652,R657,
R660,R661,R662,R664,R667,R668,R669
57 2RS1-10-101J Chip Resistor 1005,100±5% PCS 2 R284,R656
58 2RS1-10-100J Chip Resistor 1005,10±5% PCS 5 R207,R267,R285,R326,R367
59 2RS1-10-000O Chip Resistor 1005,0 PCS 13
C226,C230,R269,R276,R287,R297,C318,R322,
R375,R454,R515,C551,R580
60 2RE1-16-1503 Chip Precision Resistor 1608,150K±1% PCS 6 R526,R527,R528,R529,R530,R531
61 2LW1-20UC-221J Chip Wire Inductor
2012,220nH±5%, ceramic chip
(LQN21AR22J/LQW2BHNR22J03L)
PCS 1 L509
62 2LW1-16UC-680J Chip Wire Inductor 1608,68nH±5%, ceramic chip (C1608CB-68NJ) PCS 2 L528,L529
63 2LW1-16UC-120G Chip Wire Inductor 1608,12nH±2%, ceramic chip (C1608CB-12NG) PCS 1 L103
64 2LL1-16-R10J Stacked Inductor
1608,0.1uH±5%(MLG1608BR10J\MLG1608B10
0NJ/HK1608R10J-T)
PCS 1 L640
65 2LL1-16-27NJ Stacked Inductor 1608,27nH±5%(MLG1608B27NJ) PCS 1 L100
66 2LH1-R501R5-L05-05 Chip Air-cored Inductor 0.50*1.5*5TL, negative, high pin PCS 1 L511
67 2LH1-R401R5-R04-05 Chip Air-cored Inductor 0.40*1.5*4TL, pin height 0.5mm, positive PCS 1 L502
68 2LH1-R401R5-R03-05 Chip Air-cored Inductor 0.40*1.5*3TL, pin height 0.5mm, positive PCS 4 L527,L523,L501,L503
69 2LH1-R401R5-L08-05 Chip Air-cored Inductor 0.40*1.5*8TL, negative, high pin PCS 1 L510
70 2CT1-TS35-100-470M Chip Ta Capacitor 3528,47F±20%,10V,TS model (size B) PCS 1 C725
71 2CT1-TP20-100-4R7M Chip Ta Capacitor 2012,4.7F±20%,10V,TP model (size P) PCS 8 C454,C457,C459,C465,C562,C571,C715,C717
72 2CT1-TP20-100-100M Chip Ta Capacitor 2012,10F±20%,10V,TP model (size P) PCS 6 C267,C269,C468,C473,C475,C560
73 2CC1-16-X7R500-471K Chip Multilayer Capacitor 1608,470P±10%,50V,X7R PCS 2 C458,C461
74 2CC1-16-X7R500-104K Chip Multilayer Capacitor 1608,100nF±10%,50V,X7R PCS 2 C452,C462
75 2CC1-16-X7R500-102K Chip Multilayer Capacitor 1608,1000P±10%,50V,X7R PCS 7 C455,C464,C469,C476,C480,C534,C578
76 2CC1-16-X5R160-105K Chip Multilayer Capacitor 1608,1F±10%,16V,X5R PCS 1 C460
77 2CC1-16-C0G500-820J Chip Multilayer Capacitor 1608,82P±5%,50V,C0G PCS 1 C504
78 2CC1-16-C0G500-6R0C Chip Multilayer Capacitor 1608,6P±0.25P ,50V,C0G PCS 1 C505
79 2CC1-16-C0G500-5R0C Chip Multilayer Capacitor 1608,5P±0.25P,50V,C0G PCS 3 C509,C510,C519
80 2CC1-16-C0G500-471J Chip Multilayer Capacitor 1608,470P±5%,50V,C0G PCS 2 C518,C584
81 2CC1-16-C0G500-470J Chip Multilayer Capacitor 1608,47P±5%,50V,C0G PCS 1 C506
82 2CC1-16-C0G500-3R5C Chip Multilayer Capacitor 1608,3.5P/3.6±0.25P,50V,C0G PCS 1 C503
83 2CC1-16-C0G500-2R0C Chip Multilayer Capacitor 1608,2P±0.25P,50V,C0G PCS 2 C501,C508
84 2CC1-16-C0G500-221J Chip Multilayer Capacitor 1608,220P±5%,50V,C0G PCS 2 C218,C219
85 2CC1-16-C0G500-1R5C Chip Multilayer Capacitor 1608,1.5P±0.25P,50V,C0G PCS 1 C502
86 2CC1-16-C0G500-180J Chip Multilayer Capacitor 1608,18P±5%,50V,C0G PCS 2 C580,C585
87 2CC1-16-C0G500-110J Chip Multilayer Capacitor 1608,11P±5%,50V,C0G PCS 1 C574
88 2CC1-16-C0G500-101J Chip Multilayer Capacitor 1608,100P±5%,50V,C0G PCS 1 C532
89 2CC1-16-C0G500-100D Chip Multilayer Capacitor 1608,10P±0.5P,50V,C0G PCS 2 C523,C525
90 2CC1-10-X7R500-472K Chip Multilayer Capacitor 1005,4700P±10%,50V,X7R PCS 1 C330
91 2CC1-10-X7R500-392K Chip Multilayer Capacitor 1005,3900P±10%,50V,X7R PCS 1 C314
92 2CC1-10-X7R500-103K Chip Multilayer Capacitor 1005,10nF±10%,50V,X7R PCS 8 C214,C315,C530,C541,C543,C547,C716,C728
93 2CC1-10-X7R500-102K Chip Multilayer Capacitor 1005,1000P±10%,50V,X7R PCS 20
C212,C234,C238,C252,C277,C319,C323,C539,
C540,C548,C549,C558,C567,C572,C718,C727,
C730,C731,C733,C329
94 2CC1-10-X7R160-473K Chip Multilayer Capacitor 1005,47nF±10%,16V,X7R PCS 4 C271,C272,C276,C726
95 2CC1-10-X7R160-333K Chip Multilayer Capacitor 1005,33nF±10%,16V,X7R PCS 2 C678,C325
96 2CC1-10-X7R160-223K Chip Multilayer Capacitor 1005,22nF±10%,16V,X7R PCS 2 C681,C324
97 2CC1-10-X7R160-104K Chip Multilayer Capacitor 1005,100nF±10%,16V,X7R PCS 18
C211,C227,C233,C310,C312,C316,C317,C331,
C409,C472,C474,C477,C478,C531,C544,C550,
C723,C729
98 2CC1-10-X7R100-105K Chip Multilayer Capacitor 1005,1F±10%,10V,X7R PCS 5 C244,C245,C328,C714,C724,C327
99 2CC1-10-C0G500-471J Chip Multilayer Capacitor 1005,470P±5%,50V,C0G PCS 32
C209,C220,C228,C232,C311,C313,C320,C321,
C322,C326,C333,C429,C430,C431,C432,C433,
C524,C528,C529,C536,C537,C538,C542,C546,
C555,C556,C559,C561,C563,C568,C569,C577,
C719,C722
100 2CC1-10-C0G500-3R0C Chip Multilayer Capacitor 1005,3P±0.25P,50V,C0G PCS 1 C302
