Kirisun TM84001 Service Manual

TM840 Service Manual
64 1IS1-SKY72310 PLL IC 1 U103
65 1IS1-SYM25DHW Chip Mixer 1 IC3003
66 1IS1-TA75W01FU R Chip Special IC 1 U25
67 1IS1-TLV5614 DA convertor IC 1 U105
68 1IS1-TLV320AIC3104 Chip audio decoding IC 1 U17
69 1IS1-TPS54331DDA Chip switching power supply IC 1 U1
70 1IS1-TS3A4751PWR Chip SPST analog switch IC 1 U34
71 1TC1-UMC4 R Chip multiple-unit tube 5 U26，U27，U28，U108，U109
72 1IS1-XC0450E20S Directional Coupler 1 U48
73 1IS1-TC75S51F Chip Single operational amplifier IC 1 U21
74 1IS1-AD8315 50dB GSM Power amplifier controller 1 IC2
75 1IS1-AD8566 Dual operational amplifier 2 IC1，IC3
76 2RS1-10-201J Chip Resistance 5 R120，R129，R130，R122，R128
77 2RS1-10-102J R Chip Resistance 5 R152，R145，R121，R144，R151
78 2RS1-10-000O R Chip Resistance 3 R127，R123，R38
79 2RS1-10-472J R Chip Resistance 10 R161，R162，R165，R178，R181，R183，R184，R163，R415，R417
80 2RS1-10-103J R Chip Resistance 22
R164，R168，R171，R172，R173，R175，R179，R180，R169，R167，R174，R188，R133，R134，R189，R386，R125，R155，R146，R139，
R148，R142
81 2RS1-10-512J R Chip Resistance 2 R182，R131
82 2RS1-10-203J R Chip Resistance 2 R170，R387，
83 2RS1-10-185J R Chip Resistance 1 R379
84 2RS1-10-473J R Chip Resistance 1 R385
85 2RS1-10-101J Chip Resistance 5 R278，R309，R321，R383，R390
86 2RE1-16-1002 R Chip Precision Resistance 2 R1，R238
87 2RS1-16-334J R Chip Resistance 1 R2
88 2RS1-16-104J R Chip Resistance 12 R22，R5，R9，R16，R113，R114，R115，R4006，R289，R10，R20，R425
89 2RE1-16-2001 Chip Precision Resistance 8 R106，R12，R251，R192，R232，R291，R18，R389
90 2RS1-16-474J R Chip Resistance 2 R13，R343
91 2RS1-16-100J R Chip Resistance 2 R4，R21
92 2RS1-16-683J R Chip Resistance 3 R6，R358，R325
93 2RS1-16-513J R Chip Resistance 1 R7
94 2RS1-16-154J R Chip Resistance 1 R11
95 2RS1-16-393J R Chip Resistance 5 R292，R356，R371，R333，R406
40

Kirisun TM84001 Specifications

General

Brand	Kirisun
Model	TM84001
Category	Radio
Language	English
