TM840 Service Manual
229 7MBC-4073-06A-W STM-U audio power amplifier shielding frame 1 P3
230 7MBC-4073-05A-W STM-U_9864 shielding case 1 P4
231 1MR3-MAX-6Q
U-BLOX GPS module AP570 ， DM580 ，
STP,STM,STR
1 U9
232 2CC1-33-X5R160-476M SMD capacitor 1 C5
233 2CC1-10-X7R160-104K R chip multilayer capacitor 10 C140,C148，C231, C266，C271，C275,C145，C146，C150，C151
234 2LW1-20UC-560GB SMD wire wound inductor 1 L114
235 2RS1-16-273J R chip resistor 1 R72
236 2CC1-16-C0G500-821J chip multilayer capacitor 1 C312
237 5FC1-DSF51R6M-0705
R SMD crystal filter, PT568/78/72/62/65/
68/DR55/DM58/3208/V68/E66
2 Z1,Z202
238 2LW1-20UC-470J R wire wound inductor 1 L16
239 2CC1-16-C0G500-160J R chip multilayer capacitor 3 C4007,C238,C269
240 2CC1-16-C0G500-560J R chip multilayer capacitor 2 C4011,C4006
241 2CC1-32-C0G501-120J Chip multilayer capacitor 1 C588
242 2CC1-32-C0G102-8R0J R chip multilayer capacitor 1 C586
243 2CC1-16-C0G500-201J Vhip multilayer capacitor 5 C261,C262,C263,C264,C265
244 2CC1-32-C0G102-220J R chip multilayer capacitor 1 C320
245 2CC1-32-C0G102-100J R chip multilayer capacitor 1 C319
246 2CC1-16-X7R500-222K R chip multilayer capacitor 1 C470
247 2CC1-16-C0G500-300J R chip multilayer capacitor 1 C447
248 2LL1-16-3R3K R laminated inductor 3 L133,L129,L4004
249 2LW1-16UC-271G SMD wire wound inductor 2 L115，L52
250 2LW1-16UC-560J R SMD wire wound inductor 1 R201
251 2CC1-16-C0G500-240J R chip multilayer capacitor 2 C504,C237
252 2RS1-16-820J Chip resistor 1 R213
253 2RS1-16-301J Chip resistor 4 R324,R361,R347,R374
254 2LW1-16UC-330J R SMD wire wound inductor 1 L15
255 2RS1-16-181J R Chip resistor 3 R233,R206,R340
256 2LH1-R903R0-L05-05 R SMD air core inductor 5 L68,L69,L70,L71,L18
257 2LL1-16-1R0K R laminated inductor 3 L112,L41，FB34
258 2CC1-32-C0G501-2R0C chip multilayer capacitor 1 C589
259 2CC1-16-C0G500-430J R chip multilayer capacitor 2 C438,C527
260 2CC1-32-C0G102-180J R chip multilayer capacitor 2 C590,C592
261 2CC1-16-C0G500-R75B chip multilayer capacitor 2 C455,C510
262 2LW1-20UC-120J SMD wire wound inductor 5 L39,L45,L50,L30,L33
263 2RS1-20-000O R Chip resistor 1 R346
264 2RE1-16-5102 R SMD precision resistor 2 R412，R392
265 2RE1-16-2700 SMD precision resistor 1 R391
266 2RS1-16-202J R chip capacitor 1 R28
54
