TM840 Service Manual
23 7MBR-4025-02A-W0 DM890 Aviation plug Waterproof Ring 1
24 7MHR-7069-08A-W0 O-Ring 13
25 7MBL-4073-01A-W-A STM-U aluminum alloy Bracket (Drop rubber ) 1
26 7MBL-4062-02A-W-A DM850 Aluminum alloy cover (Drop rubber) 1
27 7MBL-4062-03B-W DM850 aluminium alloy lower cover 1
28 7MBS-4062-01A-W DM850 Keypad Metal Dome 1
29 7MHS-1140-01A-W 3118/3208 Knob circlip 1
30 7MBS-4073-01B-W STM-U_LCD Bracket 1
31 7MBF-4073-01A-Z0 STM-U_DB base waterproof cover 1
32 7NRC-120150032-N STM-U Antenna nut 1
33 7NRC-063095021-G STM-U_GPS Antenna nut 1
34 7MBS-4073-04A-W STM-U_GPS Antenna head waterproof washer 1
35 7MBS-4073-05A-W STM-U_ power module shield cover 1
36 7MBS-4073-06A-W STM-U Base Band Shield Cover 1
37 7MHC-4049-08A-W KH620D RF Board Top Shield Cover 1 1
38 7NRC-060104023-W M6x0.35 nut 1
39 7MBM-S4073-A STM-U EMI Gasket, 1
40 7MBM-S4073-A3 STM-U Ground EMI Gasket A 2
41 7MBM-S4073-A4 STM-U Ground EMI Gasket B 3
42 7GGM-4073-03A-W STM-U_GPS Connector spongy cushion 1
43 3CR7-S4025-A2 DM890_GPS Antenna Connector 1
44 6PF7-4073-HL2B STM-U Mobile FPC 1
45 4PC7-4038H-A LCD Display 1
46 7SMF-025050M-MHYB-B M2.5*5 Oblate Warbler Machine Screw 3 Fix bottom cover and aluminium alloy bracket
47 7SAF-030080M-SZYB-Z1 M3*8 Round Flat Head group Machine Screw 2 Fix power module
48 7SMF-030120M-MHYB M3*12 TORX round head Machine Screw, 4 Fix bottom cover of aluminium alloy
49 7STF-026160M-MHHT-Z ST2.6*16 Self-tapping Screw 6 Fix upper cover and bottom cover
50 7STF-026060B-SZYB-Z M2.6*6 Cross Round Flat Head With convex tooth machine screws 2 Fix keypad board
51 7SMF-030160M-MHYB M3*16 Round Head Plum Blossom Machine Screw 9 Fix upper cover of aluminium alloy
52 7SMF-030060M-SZYB-N M3*6 Cross Round Flat Head machine screws 4 Fix main board
53 1MR3-RA30H4047M Power module 1 25W400-470mHz
53 1MR3-RA55H4047M UHF RF Amplifier IC 1 40W400-470mHz
53 1MR3-RA30H1317M Power module 1 25W136-174mHz
53 1MR3-RA60H1317M Power module 1 45W136-174mHz
53 1MR3-RA30H3340 Power module 1 25W350-390mHz
53 1MR3-RA55H3340M Power module 1 40W350-390mHz
56
