BPC955V0 User Manual
EMS955V0 AMF CONTROLLER1.doc Page 6 of 19 8/06/2011
Mains AC Monitoring
Function Description
AC Phase Voltage
Monitors 1, 2 or 3 phases of AC voltage with optional configuration
parameters and clear LCD status messages. Measurements include L-N
and L-L.
AC Phase Frequency
Monitors 1, 2 or 3 phases of AC frequency with optional configuration
parameters and clear LCD status messages.
AC Phase Reversal
Monitors Mains AC for Phase reversal with optional configuration
parameters and clear LCD status messages.
Mains Failure
Monitors AC failure with optional configuration parameters and clear LCD
status messages. Includes Under and Over Voltage, Under and Over
Frequency,
System LED Indications
Function Description
Alarm Red LED indication of system alarm.
Manual Mode Green LED indication that the unit is in Manual Start Mode.
Auto Mode Green LED indication that the unit is in Automatic Start Mode
Test Mode Green LED indication that the unit is in Test Mode
Transfer Control LED Indications
Function Description
Alternator Phase 1 Available Red LED indication that the Alternator phase 1 voltage is available.
Alternator Phase 2 Available Yellow LED indication that the Alternator phase 2 voltage is available.
Alternator Phase 3 Available Blue LED indication that the Alternator phase 3 voltage is available.
Alternator Available Green LED indication that the Alternator is available for the load.
Alternator on Load Green LED indication that the Alternator is on load.
Mains AC Phase 1 Available Red LED indication that the mains phase 1 voltage is available.
Mains AC Phase 2 Available Yellow LED indication that the mains phase 2 voltage is available.
Mains AC Phase 3 Available Blue LED indication that the mains phase 3 voltage is available.
Mains AC Available Green LED indication that the mains is available for load.
Mains AC on Load Green LED indication that the mains is on load.
System LCD Displays
Function Description
Setup menu System configuration menus
Start Up Clear step-by-step start up sequencing messages
Shutdown Clear step-by-step shutdown sequencing messages
Transfer Clear step-by-step load transfer messages
