BPC955V0 User Manual
EMS955V0 AMF CONTROLLER1.doc Page 7 of 19 8/06/2011
AC Inputs
Function Description
3 Phase Mains AC Voltage Mains AC voltages.
3 Phase Alternator AC
Voltage
Alternator AC voltages.
3 Phase Alternator Current Alternator AC currents via external 5A CTs.
Analog Inputs
Function Description
Speed Engine speed from MPU or battery charging alternator.
Lubrication Oil Pressure Engine oil pressure. Exciting current approx 13mA
Lubrication Oil Temperature Engine oil temperature. Exciting Current approx 5mA
Coolant Temperature Engine coolant temperature (Air or Water). Exciting current approx 5mA
Fuel Level Engine fuel level. Exciting current approx 13mA
Canopy Temperature Engine canopy temperature. Exciting Current approx 5mA
Coolant Level Engine Radiator level. Exciting frequency 500Hz
Battery Voltage (Internal) Battery Voltage is measured internally from DC supply point.
Digital Inputs
Function Description
Auto Start / Stop Input Auto start.
Close to common. Current limited 10mA at 10V
Emergency Stop Input Emergency engine stop.
Selectable Open or Close to common. Current limited 10mA at 10V
Oil Switch Input Oil Pressure Switch sensor.
Close to common. Current limited 10mA at 10V
Digital Input 1
Configurable. Default = Bypass. No logic control but full instrumentation
available.
Digital Input 2 Configurable. Default = Canopy door open.
Close to common. Current limited 10mA at 10V
Digital Input 3 Configurable. Default = Fire. Shutdown genset and open both contactors.
Close to common. Current limited 10mA at 10V
Digital Input 4 Configurable. Status, Warning, Alarm, PC programmed message.
Close to common. Current limited 10mA at 10V
