EMS955V0 AMF CONTROLLER1.doc Page 8 of 19 8/06/2011
Outputs
Function Description
Excitation Output Alternator excitation control and feedback. 200mA Pulsed
Preheat Output Open drain engine preheat control. Open Drain 300mA /36V DC
Fuel Output Open drain fuel solenoid control. Open Drain 300mA /36V DC
Crank Output Open drain engine crank control. Open Drain 300mA /36V DC
Idle Output Open drain engine idle control. Open Drain 300mA /36V DC
Hooter Output Open drain audible sounder control. Open Drain 300mA /36V DC
Common Alarm Output Open drain audible sounder control. Open Drain 300mA /36V DC
Contactor A Output Open drain transfer contactor A control. Open Drain 300mA /36V DC
Contactor B Output Open drain transfer contactor B control. Open Drain 300mA /36V DC
