KIRLOSKAR CPHM - Page 13

4.
4
(a)
SPECIFICATIO
NS
OF
STUFFIN
G
BOX
PACKING
GASKET
AND
“O”
RING
FOR
DRIVING
U
NITS
5,7,9
IOM
/CPHM/
DEC19
/0
1
Page: Page 12 of 48
Issue Date:
14/12/2019
Revision No.:1
PART
NO.
DESCRIPTION
UNIT NO.
CPHM 5 CPHM 7
CPHM 9
50/20
40/20 32/20 50/16 40/16 32/16 65/13 50/13 40/13 32/13
50/32
40/32 25/26 80/20 65/26 50/26 40/26 32/26 100/20 80/20 65/20 80/16 65/16
65/43
65/40 150/40 125/40 100/40 80/40 150/32 125/32 100/32 80/32 65/32 125/26 100/26
GLAND PACKING ARRGT. WITH
LANTERN RING
2 + L + 3 2 + L + 3 2 + L + 3
4300001 GLAND PACKING SIZE
(O.D. x I.D. x THICK)
51 x 35 x 8 65 x 45 x 10 75 x 55 x 10
STRAIGHT LENGTH OF GLAND
PACKING IN mm.
140 180 205
5110001 GASKET FOR CASING & CASING
COVER
114 ID x
152 OD x
1 TH
176 ID x
188 OD x
1 TH
216 ID x
230 OD x
1 TH
176 ID x
188 OD x
1 TH
216 ID x
230 OD x
1 TH
266 ID x
282 OD x
1 TH
331 ID x
348 OD x
1 TH
266 ID x
282 OD
x 1 TH
331 ID x
348 OD x
1 TH
411 ID x
432 OD
x 1 TH
431 ID x
450 OD
x 1 TH
5140001 GASKET FOR BEARING COVER
78 SQ x 1 T 112 x 102 x 1 TH 124 x 134 x 1 TH
5150001 GASKET FOR IMPELLER AND
SHAFT SLEEVE
30 OD x 25 ID x 1 TH 40 OD x 35 ID x 1 TH 50 OD x 44 ID x 1 TH
5160001 GASKET FOR MECH. SEAL
52 ID x 64 OD x 1 T 76 ID x 94 OD x 1 T 76 ID x 94 OD x 1 T
5250101 “O” RING FOR CASING COVER
104 ID x 3 TH 123 ID x 3 TH 145 ID x 3 TH
5231101 “O” RING FOR BEARING
HOUSING
125 ID x 3 T 150 ID x 3 T 150 ID x 3 T
5250201 ‘O’ RING FOR LANTERN BRACKET
142 ID x
3 TH
175 ID x
3 TH
215 ID x
3 TH
175 ID x
3 TH
215 ID x
2
3 TH
88 ID x 3 TH
85 ID x
3 TH
265 ID x 3 TH
5230301 ‘O’ RING FOR BEARING
CARTRIDGE
72 ID x 3 TH 108 ID x 3 TH
6820001 GASKET FOR IMPELLER AND
IMPELLER NUT
28 OD x 20 ID x 1 TH 38 OD x 28 ID x 1 TH 48 OD x 38 ID x 1TH
6850001 GASKET FOR OIL WELL COVER
99 OD x 55 ID x 1 TH 99 OD x 55 ID x 1 TH 99 OD x 55 ID x 1 TH
NOTE: CORRECT LIQUID SPECIFICATIONS SHOULD BE INFORMED TO US TO RECOMMEND SUITABLE GRADE OF ST. BOX PACKING.
ALL DIMENSIONS ARE IN MM.
