KIRLOSKAR DSM Series User Manual

IOM/DSMT/0010/01 Issue Date: 13/10/2000
Page : Page 6/14 Last Revision Date:
4.5.7 Technical data Chart
PUMP TYPE
“DSM” ---------------->
DSM
50/20
DSM
65/20
DSM
50/28
DSM
65/32 A/B
DSM
80/36
FLANGE SIZE IN MM
DEL. x SUC.
50 x 80 65 x 100 50 x 65 65 x 80 80 x 100
BALL BEARING NO.
SKF OR EQUIV.
DRIVING END
6307 6309 6306 6306 6307
NON DRIVING END 6307 6408 6306 6306 6307
QTY. OF GREASE
PER BRG. Gms 100 100 100 100 100
ST. BOX PACKING
SIZE IN MM.
SIZE x LENGTH
10 SQ x
1660
10 SQ x
2010
10 SQ x
1560
10 SQ x
1560
10 SQ x
1650
POSITION OF
LANTERN RING (L)
FROM IMPELLER
SIDE (NDE SIDE) 2+L+3 2+L+3 2+L+2 2+L+3 2+L+2
NO. OF PACKING RINGS
DE (Lantern ring is not
required of DE side)
6 6 5 6 6
NDE(Lantern ring is not
required of DE side)
5 5 4 5 4
COUPLING:
FLEXIBLE JOY TYPE
KWS 150 KWS 225 KWS 110 KWS 190 KWC 226
