14
15. Exhaust manifold
16. Charging Alternator
17. Starter
18. Crankcase
19. Crankcase Breather
20. Flywheel Housing
21. Flywheel
22. Turbocharger
23. Air Intake Manifold
2. Engine Description 2.2 Engine Illustration
2.2.4. Exhaust Side.
HA694 TC
