KIRLOSKAR KMW MIN T 8 DLX User Manual

ROTOR TILLER AND COVER ASSEMBLY MIXING TYPE
PART NO
PART NAME
QTY.
1
P08.D011.021.0.00
RUBBER DAMPING SLEEVE
2
2
P08.D011.081.0.00
FENDER
1
3
50.911.08.016
FLANGE BOLTS M8X16
12
4
50.911.06.025
FLANGE BOLT M6X25
2
5
P08.D011.082.0.00
SIDE FENDER
2
6
P08.D015.071.0.00
SPLINE CONNECTING SEAT
2
7
P08.D011.023.0.00
REAR TINE TILLER-RIGHT BLADE
10
8
P08.D011.022.0.00
REAR TINE TILLER-LEFT BLADE
10
9
57.002.06.035
HEX BOLT M6X35
16
10
P08.D011.071.0.00
ROTOR SHAFT MIXING TYPE
4
11
57.002.06.025
HEX BOLT M6X25
8
12
57.002.08.025
HEX BOLT M8X25
4
13
57.507.08.000
SPRING WASHER M8
4
14
P08.D015.073.0.00
BOX BRACKET
1
15
P08.D015.023.0.00
GASKET, BOX BRACKET
1
SR.NO.

.,5/26.$52,/(1*,1(6/,0,7('

$.LUORVNDU*URXS&RPSDQ\
