16 P08.D015.041.0.00 REAR TINE TILLER CRANK CASE 1
17 P08.D015.002.0.00 DRAIN BOLT –REAR TINE TILLER CASE
1
18 P08.D015.051.0.00 OUTPUT SHAFT 1
19 P08.D015.052.0.00 REAR TINE TILLER BEVEL GEAR 1
20 P08.D015.024.0.00 DEEP GROOVE BALL BEARING 2
21 P08.D015.025.0.00 OIL SEAL 2
22 P08.D015.042.0.00 CRANKCASE COVER 1
23 50.911.08.035 HEX BOLT M8X35 4
24 57.505.08.000 SPRING WASHER M8 4
25 50.008.16.000 LOCK NUT M14 2
26 P08.D015.026.0.00 BEARING 3204 1
27 P08.D015.053.0.00 REAR TINE TILLER DRIVE SHAFT 1
28 P08.D015.027.0.00 DEEP GROOVE BALL BEARING 6004 1
29 P08.D015.028.0.00 OIL SEAL 28*42*7 1
30 P08.D015.074.0.00 COUBLING END 1
31 P08.D015.029.0.00 O-RING Ø21 1
32 57.507.08.000 PLAIN WASHER M8 1
33 50.911.06.016 FLANGE BOLT M6X16 1
34 P08.D011.083.0.00 RIGHT SIDE PLATE 1
35 50.911.12.090 FLANGE BOLTS M12X90 1
36 57.507.12.000 PLAIN WASHER M12 1
37 50.008.12.000 LOCK NUT M12 1
38 57.507.10.000 PLAIN WASHER M10 4
39 P08.D015.082.0.00 LARGE PANEL 1
40 P08.D015.083.0.00 TILLAGE DEPTH ADJUSTMENT PLATE 1
41 P08.D011.001.0.00 SPACER PIN 1
42 57.507.10.000 PLAIN WASHER M10 1
43 P08.D011.031.0.00 RESET SPRING 1
44 P08.D011.002.0.00 SPLIT WASHER M10 1
45 P08.D011.003.0.00 SPLIT PIN 2
46 P08.D011.085.0.00 LEFT SIDE PLATE 1
47 P08.D015.030.0.00 ADJUSTABLE HANDLE 1
48 P08.D015.076.0.00 REGULATING HANDLE SHEATH 1
49 P08.D015.075.0.00 TRANSMISSION SUPPORT PLATE 1
PART NO PART NAME QTY.
SR.NO.
ROTOR TILLER AND COVER ASSEMBLY MIXING TYPE
