KIRLOSKAR KMW MIN T 8 DLX User Manual

DRIVE WHEEL SYSTEM
SR.NO.
PART NO
PART NAME
QTY.
1
P08.D009.021.0.00
BEARING 6205

2
P08.D009.022.0.00
HUB GASKET

3
P08.D009.001.0.00
CIRCLIP FOR HOLE Φ47

4
P08.D009.023.0.00
BEARING 6005

5
P08.D009.024.0.00
OIL SEAL 30X42X8

6
P08.D009.002.0.00
CIRCLIP FOR SHAFT 25

7
P08.D009.041.0.00
HUB FOR REDUCTION UNIT WHEEL

8
P08.D005.003.0.00
SCREW M8X25

9
57.002.10.40
HEX BOLT M10X40


10
P08.D009.081.0.00
INSIDE SEMICIRCLE FOR WHEEL

11
P08.D009.025.0.00
WHEEL ASSY


12
57.507.10.000
PLAIN WASHER M10

13
57.505.10.000
SPRING WASHER M10

15
57.006.10.000
HEX NUT M10

16
57.002.10.040
HEX BOLT M10X40


.,5/26.$52,/(1*,1(6/,0,7('

$.LUORVNDU*URXS&RPSDQ\
