Chapter 5 : LED Function
5-1. Powerline Ethernet adapter (PE-14)
LED LED STATUS INDICATION
Blinking Collisions Occuring
Off No Collisions
Blinking Looking for Powerline Devices
On Network Traffic
Off No Network Traffic
On Powerline Connection Established
Off No Powerline Connection
Blinking Ethernet Activity
On Port Linked
Off No Ethernet Traffic
Link Activity
(Link Act)
Link
(LINK)
Activity
(ACT)
Collisions
(COL)
