USB Charger Kit Instructions
Start by gluing 5 of the 6 box sides
together. Do not glue the “top”
piece at this time. Each side cutout
fits a specific component.
Start Connecting Wires
+
-
OUT+
B
+
B
-
OUT-
Begin by connecting the Battery to the Micro
USB Charging Module (blue board). This is
how you charge the battery with a wall plug
via a USB adapter.
Insert the battery wires into the terminals as
shown (Red to B+, Black to B-) and secure
with solder. Use wire strippers to carefully
remove excess solder, if any, on the tinned
ends of wires in the kit so the ends can be
inserted into the appropriate terminal holes.
LIPO
BATTERY
Switch
Standard USB
(green board)
Micro USB
(blue board)
