KitchenAid KDRP467KSS09 - Oven Parts

OVEN PARTS
2
For Model:KDRP467KSS09
(Stainless Steel)
8186532
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
9760618 Installation
Instructions
9763070 Use & Care Guide
8302207 Tech Sheet
9759441 Conversion
Instructions
3191638 Safer Cooking Tips
9759133 Safer Cooking Tips
2 4449809 Screw, 8−18 x 3/8
6 4452260 Spacer, Foam
7 9761161 Top, Chassis
8 4448520 Bumper, Door
9 4452158 Tube, Vent
10 4452163 Lens, Light
11 4448972 Oven Light Assy
12 4452164 Bulb, Light
13 Hinge Receiver
4455605 Left Hand
4455606 Right Hand
14 9762238 Frame, Front
15 8300142 Gasket, Door
16 4452152 Bracket, Mounting
19 8300184 Support, Insulation
21 4455510 Bracket, Support
24 9760889 Latch, Motorized
25 4455641 Side, Chassis
26 9761160 Back, Chassis
27 Liner, Oven
(Not serviceable)
29 4455636 Sensor
30 4449154 Screw, 8−32 x .440
31 4449040 Screw, 8−18 x 3/8
32 3196176 Screw, 8−18 x 1/2
37 4450249 Thermostat (TOD)
(Temp.) SPST 150c
43 8300965 Base, Chassis
49 4448933 Retainer, Gasket
50 9758583 Cover, Back
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
8300158 Insulation, Wrap
8300159 Insulation, Back
