4
Location Requirements
Dishwasher must be fully enclosed (top, sides, back, and floor)
upon installation. A side panel kit is available from your dealer for
installing your dishwasher at the end of your cabinetry.
An optional moisture barrier accessory is also available for
installing underneath a wooden countertop. See the “Tools and
Parts” section at the front of the guide for part details and orders.
Check location where dishwasher will be installed. The location
must provide:
■ Convenient access for loading and unloading dishes. Corner
locations require a 2" (5.1 cm) minimum clearance between
the side of the dishwasher door and the wall or cabinet.
■ Easy access to water, electricity and drain.
■ Grounded electrical supply required.
■ Make sure pipes, wires and drain hose are within the
shaded area shown in the “Product and Cabinet Opening
Dimensions” section.
■ Do not run drain lines, water lines or electrical wiring
where they can interfere with or contact dishwasher motor
or legs.
■ Shelter dishwasher and water lines leading to dishwasher
against freezing. Damage from freezing is not covered by
the warranty.
NOTE: If dishwasher will be left unused for a period of time or
in a location where it may be subject to freezing, have it
winterized by authorized service personnel.
■ A square opening for proper operation and appearance.
■ The cabinet front to be perpendicular to floor.
■ A level floor.
Helpful Hint: If floor at front of opening is not level with floor at
rear of opening, shims may be used to level dishwasher.
NOTE: To avoid shifting during dishwasher operation, shims
must be securely attached to the floor.
■ The location where the dishwasher will be installed must
provide clearance between motor and flooring. Motor should
not touch the floor.
■ Do not install dishwasher over carpeted flooring.
