OPERATION
Built-In Single and Double Wall Ovens
n
2-1
Section 2:
Operation
n How the Oven Works
n Wiring Diagram and LOGIC circuits
n Receiving and Distribung Electricity
• The 120 VAC circuits
• The 240 VAC circuits
• Oven Appliance Manager
• User Interface/Keypad Assembly and the
Appliance Manager connecons
This secon provides a breakdown of all electrical
circuits on the wiring diagram. It also shows all
electrical power operaons of each circuit.
