10
INSTALLING THE DISCS OPERATING THE FOOD PROCESSOR ATTACHMENT
Installing the dicing disc and blade
Drive pin
2
Hold the dicing disc by the middle hole
and disc edge, chute lip-side facing
DOWN. Place the disc on top of the
liner so that the dicing grate aligns with
the liner’s feed tube.
3
Install the blade on top of the dicing disc
by sliding it onto the drive pin.
4
Install the lid by turning counter
clockwise, being sure it locks into place.
1
Insert the liner into the attachment
assembly so that the feed tubes line
up and the liner lies flat.
W10641290A_ENv13.indd 10 5/28/14 11:50 AM
