INSTALLING THE DISCSINSTALLING THE DISCS
Installing the julienne disc
Drive pin
Drive pin
Disc adapter
Disc adapter
Installing the reversible shredding disc
Finger grip
Disc adapter
2
Slide the disc adapter onto the drive pin.
1
Insert the liner into the attachment
assembly so that the feed tubes line
up and the liner lies flat.
2
Slide the disc adapter onto the drive pin.
1
Insert the liner into the attachment
assembly so that the feed tubes line
up and the liner lies flat.
3
Hold the reversible shredding disc
by the 2 finger grips with the desired
shredding side facing UP. Install the disc
on the disc adapter by fitting the adapter
through the hole in the bottom of the
disc until it is seated against the liner.
4
Install the lid by turning counter
clockwise, being sure it locks into place.
