DocumentNo.:KE-0015-00                                        Sheet:22/37



IIIStrainerInstallation



7.3Spacefortheremovalofthescreen

Periodicallythescreenneedstoberemovedforclean-up.Thereforeallowsufficientroom

(indicated as H1 in the illustration below) for the removal of thecap and screen when

installing strainers to pipeline. Refer to the relevant product drawing for dimensional

information.







7.4Installationofshut-offvalvesanddifferentialpressuregauge 

Shut-offvalvesmustbeinstalledbothontheupstreamanddownsteamsideofstrainers.

Theuseofdifferentialpressuregaugesisrecommendedtodetecttheloadingofscreens.

 


