DocumentNo.:KE-0015-00                                        Sheet:21/37

IIIStrainerInstallation


7. InstallationofStrainers

7.1HorizontalPiping
Strainersmustbeinstalledinaccordancewithanarrowindicatedonthebodyinthe
horizontal pipeline. Y Strainers should be placed with the cap facing down, while U
Strainersplacedwiththecapfacingup.Ifthestrainersareinstalledotherwise,foreign
objectscaughtinthescreenwillreturnintothepipeline.












7.2VerticalPiping.
Strainersshouldbeinstalledwiththecapfacing
downintheverticalpipelinewithdownwardflow
direction. For the upward flow line, install
strainerswiththecapfacingup.However,itis
not recommended to use strainers in the
verticalpipelinewithupwardflowdirectiondue
to its inherent design feature. U Strainers will
notfunctionintheverticalpipeline. 
Flowdirection→
Flowdirection→
not
recommended
Top
Top
Bottom
Bottom
