DocumentNo.:KE-0015-00 Sheet:37/37
Ⅶ DisassemblyandReassembly
4 AssemblyIllustration
No. PartsName
1 Body
2 Cap
19 Gasket
27 Screen
33 Covernut
35 Coverbolt
75 Eyebolt
85 Plug
組立の際は納入品図を参照の上、実施してください。
ThisillustrationrepresentsatypicalconstructionoftheUStrainer.
Refertotheapprovaldrawingbeforedisassemblyandassembly.
