Kitz Y Series User Manual

DocumentNo.:KE-0015-00                                        Sheet:36/37

Ⅶ DisassemblyandReassembly 
2 AssemblyIllustration







No. PartsName
1 Body
2 Cap
19 Gasket
27 Screen
33 Covernut
35 Cover  bolt




ThisillustrationrepresentsatypicalconstructionoftheFlangedYStrainer.
Refertotheapprovaldrawingbeforedisassemblyandassembly.

3 AssemblyIllustration





ThisillustrationrepresentsatypicalconstructionoftheThreadedY
Strainer.
Refertotheapprovaldrawingbeforedisassemblyandassembly.





ThisillustrationrepresentsatypicalconstructionoftheThreadedYStrainer.
Refertotheapprovaldrawingbeforedisassemblyandassembly.

No. PartsName
1 Body
2 Cap
19 Gasket
27 Screen
