12
Input metering incorporating multi-point
clip indication. This meter indicates the
input level immediately after the input
gain trim.
dynamic EQ metering. Four
meters are provided to monitor all four
dynamic EQ filters.
Output metering incorporating multi-
point clip indication. These meters
indicate the actual level leaving the unit,
while the red clip light indicates internal
clipping (monitored throughout the
internal processing stages) irrespective of
actual output level
.
PC port connector, using a three-wire RS-
232 interface on a Mini-DIN connector.
Use with the supplied cable to install
software updates or to control the unit
from an external computer. Note that this
is entirely separate from the rear-panel
RS-232 and RS-485 connectors, and can
be used at the same time as the rear panel
connectors.
Power ON indication.
Power switch.
l abc
Identification of controls:DN9340
T-DEQ
