Technical Specifications: DN9340
Inputs Two
Outputs Two
Performance
Processing (Per Channel)
Input Gain
Delay
Filters
Dynamic EQ
Parametric EQ
Graphic EQ
Power Requirements
Terminations
Type Electronically balanced (pin 2 hot)
Impedance (Ohm) 20k
Common Mode >80dB @ 1 kHz
Rejection
Type Electronically balanced (pin 2 hot)
Maximum Level +21dBu into >2k
Frequency response 0.3dB with all filters and EQ flat
(20Hz to 20kHz)
Distortion (THD+N) @ +4dBu <0.01%
(20Hz to 20 kHz)
Dynamic range 115dB
(20Hz-20kHz unweighted)
+12dB to 40dB in 0.1dB steps plus Off
0-1 second (342.25 m or 333'10” at 20C in 20.8us steps)
4 Filters (max)
Types Low Pass, High Pass, Low Shelf, High Shelf, Notch
2 Bands (max)
Range 12dB
Responses Proportional, Constant, Reciprocal
12 Bands (max)
Range 12dB
Responses Proportional, Constant, Reciprocal
31 Bands On ISO standard frequencies
Range 12dB
Responses Proportional, Constant, Reciprocal, DN27, DN360
Voltage 90V to 250V a.c. 50/60 Hz
Consumption
Audio inputs/outputs 3-pin XLR
RS-485 inputs/outputs 3-pin XLR
RS-232 8-pin Mini-DIN socket (front)
9-pin D-type (rear)
Power 3-pin IEC
60W
Dimensions
Weight
Width 483 mm (19inch)
Height 88 mm (3.5 inch) 2RU High
Depth 303 mm (12 inch)
Nett 5.5kg
Shipping 7.0kg
51
PUSH
PUSH
PUSH
CAUTION: TO REDUCE RISK OF FIRE, REPLACE WITH SAME TYPE OF FUSE.
100-240V
FUSE: 5x20mm
T0.5L250V
AC~50-60Hz 60W
SUPPLY
VOLTAGE
CUS
A
GRAPHIC
PARAMETRIC
DYNAMIC
FILTERS
BYPASS
SELECT
A
B
TYPE
CHAN
IN
DYN
OUT
0
0
3
3
6
6
9
9
12
100
75
50
25
0
100
75
50
25
0
12
15
15
18
18
21
21
24
24
27
27
40
40
1
1
2
2
HOME
(SETUP)
RECALL
STORE
B
B
A
A
B
-
-
-
-
-
-
DN9340
DIG
IT
AL EQUALISER
