Connections:DN9340
RS-485 serial communications.
These connectors are connected in “loop
through” fashion, so either may be used
for input or output. Connectors are
balanced with:
Pin 2 Hot
Pin 3 Cold
Pin 1 Ground
RS-232 serial interface for auto
solo operation in association with
consoles.
l
abc
Mains inlet unit is auto
sensing over the range 100-
240VAC.
Audio connectors for
channelA.
Electronically balanced
with:
Pin 2 Hot
Pin 3 Cold
Pin 1 Ground
Audio connectors for
channel B.
Electronically balanced
with:
Pin 2 Hot
Pin 3 Cold
Pin 1 Ground
