Installation
• Place the machine at at oor near a window.
• To maintain a good air circulation and obtain an optimum machine performance, it shall leave a
50 cm space around.
Mounting the Window Seal
Step 1: Measure window size. Adjust the
length of the window sealing plate,
making it to t the size of the win-
dow. After the length of window
sealing plate is determined, x it
length dimension with screws.
Step 2: Install the xed window sealing
plate on the window.
Step 3: Screw the exhaust pipe assembly
(exhaust joint end) into the rear
panel exhaust port (counter clock-
wise).
Step 4: Place the exhaust pipe assembly
(exhaust at port) into the win-
dow sealing plate assembly and x
it with screws.
Important Hints on Installation
• The smoothness of exhaust pipe is very important. In-
correct installation will aect the operation of air con-
ditioners.
• In installation, avoid the exhaust pipe bending subs-
tantially.
• Ensure the air ow smoothly inside the pipe.
• The exhaust pipe length is specially designed for this
model, do not arbitrarily replace or extend it, or it will
lead to failure easily.
• The maximum developed length of exhaust pipe is
1500mm. shorten its length as far as possible in use.
It’s recommended to keep it in level in installation.
12 13
