14
Installation
1
1
2
3
If you have an outlet to the outside, your cooker hood can be con-
nected As below picture by means of an extraction duct (enamel, alu-
minum, flexible pipe or inflammable material with an interior diameter
of 150mm).
Prepare for installation
Installation (vent outside):
Before installation, turn the unit off and unplug it from the outlet.
The cooker hood should be placed at a distance of 65~75cm above
the cooking plane for best effect.
Drill 3 holes to accommodate the bracket. Screw and tighten the bracket onto the wall with the screws
& wall plugs provided.
