Installation (Vent outside)
If you do not have an outlet to the outside, exhaust pipe is not
required and the installation is similar to the one show in section
“Installation (Vent outside)”.
Pulling up the upper chimney upwards. to the target
height. Adjust to reach the height required.
Mark and drill two holes to accommodate the upper
chimney bracket with 2 pcs of wall plugs and 2 pcs of
ST4*30mm.
When finish , install the upper chimney bracket with the
upper chimney with 2 pcs of ST4*8mm.
At last , install the lower chimney to the hood body with
2 pcs of ST4*8mm.
