2. Reversing the door
Our wine cooler is delivered with the door opening from left to right. To reverse the
opening direction:
1. Open the door at 90° and keep it
steady.
2. Unscrew the M5x16 screws (2),
dismantle the right upper hinge and
remove the door (see gure1).
Figure 1
3. Unscrew the M5x16 screws (2) and
dismantle the right lower hinge (5)
(see gure 2).
Figure 2
4. Remove the germinal lid (1).
Figure 3
