39
EN
Hook position for
H=20mm top
Hook position for
H=30mm top
Hook position for
H=40mm top
N.B: Use the hooks contained in the "accessories bag".
6. In the event the gas hob is not installed on a built-in oven, a wooden panel must be
inserted for insulation. This panel must be placed at least 20 mm distance from the
bottom of hob.
lmportant: When installing the hob on a built-in oven, the oven should be placed on two
wooden strips; in the case of a joining cabinet surface, remember to leave a space of
45 x 560 mm at least from the back side.
When installing hob on a built-in oven without forced ventilation, ensure that have air
inlets and outlets to ventilate the interior of the cabinet adequately.
