3 4
Leave up the cooker hood and hang
onto the wall bracket hook.
Fix the one-way-valve to the air outlet
of the cooker hood. Then, attached
the exhaust pipe onto the one-way-
valve.
Chimney installation
Put the upper chimney into lower chimney. Then pulling
out the upper chimney upwards. Adjust to reach the
height required. Measure the appropriate height and dill
2×8 mm holes to accommodate the plate. Screw and
tighten the upper wall with 2 screws provided.
There are 2 methods for installation the chimney cover (see below pic for
reference).
1. After drilled the 2 holes and xed the hook, hang the chimney cover by
matching the both side lock (Pic1).
2. After drilled the 2 holes and xed the hook, install the chimney cover by
locking with 2 screws in both side holes (Pic2).
