34
EN
Installation accessories for window ventilation
1. Exhaust duct assembly
2. Window sealing plate assembly (sliding bar):
Installation of the window ventilation
Step 1
Measure the size of the window. Adjust the length of the Window sealing plate
to the size of the window. After adjustment, fasten theWindow sealing plate with
screws (see gure).
Exhaust joint
Exhaust air hose
Exhaust air hose adapter
Window sealing plate
Window sealing plate
