Klein Tools CL220 User Manual

11
OPERATING INSTRUCTIONS
TEMPERATURE
1. Insert K-type thermocouple into the VΩ
5
and COM
4
jacks
(observe polarity markings on thermocouple and meter), and
rotate function selector switch
2
to the Temperature setting.
NOTE: The meter defaults to Fahrenheit scale in this mode. To enter
Celsius scale, press the "SELECT" button
12
once. Ensure that the
appropriate icon (either
°F or °C ) appears on the display.
2. To measure temperature, make contact between the
thermocouple tip and the object being measured. When
thermocouple tip and object are in thermal equilibrium, the
measurement on the display will stabilize.
Remove thermocouple before switching meter to other
measurement functions.
The thermocouple included with the original purchase
is suitable for temperatures below 446°F / 230°C only. To
measure higher temperatures, a K-type thermocouple
with the appropriate measurement range should be used.
K-Type
Thermocouple

Klein Tools CL220 Specifications

General

Data hold	Yes
Product type	Digital multimeter
Product color	Black, Orange
AC current range	0 - 400 A
AC voltage range	0 - 600 V
DC voltage range	600 V
Housing material	Acrylonitrile butadiene styrene (ABS)
Measuring category	CAT III 600V
Placement supported	Handheld multimeter
Resistance resolution	20 Ω
Temperature measurement range	-40 - 1000 °C
Battery type	AAA
Power source	Battery
Battery technology	Alkaline
Number of batteries supported	3

Weight and Dimensions

Depth	215 mm
Width	89 mm
Height	38 mm
Weight	314 g
