Klein Tools TI222 - Display Details; Live Mode Screen

4
7:30 AM 25%
90.4
o
F
124.2
o
F
132.2
o
F
80.7
o
F
132.2
o
F
80.7
o
F
51.5
o
F
124.2
o
F
CAL
ENGLISH
B
N
O
M
K
L
C
G
A.
Photo/Video Gallery
B.
Center Point Temperature
C.
Differential Temperature
D.
Red Marker
(High Temperature)
E.
White Marker
(Center Point Temperature)
F.
Gray Marker
(User-Selectable Temperature)
G.
Calibrating Icon
H.
Time-Lapse Video Capture Button
I.
Photo Capture Button
J.
Video Capture Button
K.
Lowest Temperature
L.
Live Temperature Color Palete
M.
Highest Temperature
N.
Green Marker
(Low Temperature)
O.
Settings
H I J
D
E
F
DISPLAY DETAILS
LIVE MODE SCREEN
TIME-LAPSE MODE SCREEN
U
A.
Photo/Video Gallery
O.
Settings
U.
Stop Button
FIG. B
FIG. C
A
A
O
