GENERAL SPECIFICATIONS
The Klein Tools TI290 is a high resolution, USB rechargeable professional
Thermal Imager; power on to view unseen hot and cold spots for instant
troubleshooting. The meter provides high and low temperature points, crosshairs
to pinpoint specific temperatures, and options for temperature alarms. Wi-Fi
setting allows the meter to transfer and share images for reporting.
• Environment: Indoor: DO NOT expose to moisture rain or snow.
• Operating Altitude: 6562 ft. (2000 m)
• Relative Humidity: <85% non-condensing
• Operating Temp: 32° to 113°F (0° to 45°C)
• Storage Temp: -4° to 140°F (-20° to 60°C )
• Sensor: VOx Microbolometer
• Sensor Resolution: 49152 pixels (256 × 192)
• Field of View (FOV): 55.6 +/- 2.8 degrees
• Frame Rate: 9 Hz
• Sensitivity: ≤50 mK
• Temperature Range: -4° to 752°F (-20° to 400°C)
• Temperature Resolution: 0.1°F/0.1°C
• Temperature Accuracy: ±2°C (±2°F) or 2% (whichever greater)
NOTE: Not calibrated below -10°C (14°F)
• Temperature Display: High, Low, and Center point
• Temperature Settings: °F / °C
• Emissivity: 0.01 to 0.99 adjustable (0.95 default)
• Display Type: 3.5" (89 mm) TFT LCD
• Color Palettes: Ironbow, Rainbow, Grayscale
• Image Format: JPG
• Image Storage: Up to 10000 thermal images
• Image Transfer: USB, or Wi-Fi using the Klein Tools App
• Dimensions: 4.48" × 3.10" × 1.06" (113.7 × 78.7 × 26.9 mm)
• Weight: 7.5 oz. (213 g)
• Power: Lithium polymer battery (USB rechargeable)
3.7V / 2000mAh (7.4 Wh)
• Required Charger Voltage / Current : 5V DC, 2A
• Charging Current / Time: 900mA / 3 hours
• Auto Power Off: User-selectable for 5, 10, or 30 minutes
• Pollution degree: 2
• Drop Protection: 6.6' (2 m)
• Standards: Conforms to UL STD. 61010-1
Certied to CSA STD. C22.2 No. 61010-1
Specifications subject to change.
ENGLISH
WARNINGS
Read, understand, and follow these instructions to ensure safe
operation. Failure to observe these warnings can result in risk of
re or electric shock. Keep these instructions for future reference.
• DO NOT use the product if it is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire,
explosion, or injury.
• Risk of fire and burns. DO NOT open, crush, heat above specified
maximum temperature or incinerate. Prolonged exposure to
direct sunlight can result in elevated temperatures
.
• If the battery’s internal temperature gets too high, the unit will shut
down until the internal temperature is lowered.
• DO NOT expose to moisture, rain, or snow.
• DO NOT subject to impacts or drops greater than 6.6 ft. (2 m). Drops
larger than this may not show signs of damage, but internal components
may have been compromised. It is advisable to replace the unit if any
such severe events occur.
• There are no user-serviceable parts inside. DO NOT open or attempt to repair.
WARNING SYMBOLS ON TESTER
OTHER SYMBOLS ON TESTER
5001748
CAUTION
• BURN HAZARD. Reflective materials may have a higher actual
temperature than the measured temperature. Set emissivity to
match the object being measured (see Emissivity section).
• Do not point the camera at the sun or any other strong energy source.
This can affect the accuracy of the camera or cause damage to the sensor.
