ENGLISH
OPERATING INSTRUCTIONS
MENU FUNCTION
Press the Menu / Select Button
6
and the Menu and Setup functions
(shown below) will appear on the LCD. Use the Up
4
and Down
5
Scroll Buttons to scroll through the functions. Press the Menu / Select
Button
6
to open the function or make a selection. To exit the function
or hide the menu, long press the Menu / Select Button
6
.
F
Temperature Units: Selectable between °F and °C.
G
Center Target Temperature and High / Low Temperature:
Turns these icons on or off.
H
Color Palettes: Selectable between Ironbow, Rainbow, and Grayscale.
I
Gallery: Scroll through and view captured images.
J
Settings:
• WiFi Image Transfer: Connects to KleinTools App to transfer files.
• Temp Bar: Turns feature on or off.
• Time & Date: Sets time and date stamp for images.
• Emissivity: Adjustable from 0.01 to 0.99 (default is 0.95).
• Auto Power Off: Set to 5, 10, or 30 minutes.
• Brightness: User-selectable low, medium, or high.
• HI/LO Alert: Sets temperature alarms.
• Local Info: Provides information on firmware version, memory
capacity, memory available, and battery temperature.
• Default Settings Reset: Restores factory-default settings.
• Erase All Images: Permanently deletes all images from TI290.
IMAGE CAPTURE
Press Camera Shutter Button
3
to take a image. NOTE: Menu
E
must be hidden to take an image.
Press the Up Scroll Button
4
to save the image, or the Down Scroll
Button
5
to discard image.
Wi-Fi TRANSFER
On the imager:
Press the power button
2
for 2 seconds to power on the TI290. Next press
the Menu/Select button
6
to access the Menu. Use the Up
4
and Down
5
Scroll Buttons to scroll to the Settings menu and press the Menu/Select button
6
. Select WiFi Photo Transfer (first item); press the Menu/Select button
6
.
LCD will read " TURNING ON WIFI ", then " WAITING FOR CONNECTION FROM
MOBILE DEVICE, Follow instructions in Klein Tools APP ".
On your device:
Download the Klein Tools App (available for free from Google Play
TM
or
the App Store
®
). Launch the Klein Tools App on your device. To properly
connect to TI290 and store images on your device, accept all pop-up
app permissions. Tap the "Connect" button on the app and select/join
the KT-TI290 Wi-Fi network. If your device prompts you to connect to
device, tap the "Connect" button. If the KT-TI290 Wi-Fi network is not
found, ensure that Wi-Fi is enabled in your device's settings.
Once connected, tap the "Transfer Photos" button. All images will
transfer from TI290 to your device. Select the images you want to
save and press the "Save To Phone" button. Saved images can now
be accessed in the app's gallery and selected and shared using your
device's standard options.
OPERATING INSTRUCTIONS
BATTERY INDICATOR
D
• Solid Green: Battery has more than 40% charge remaining
• Partial Yellow: Battery has less than 40% charge remaining
• Partial Red: Low battery, needs recharging
• Blinks Red 10 Times: No Power, Immediate Shut Down
EMISSIVITY
Emissivity is a measure of the ability of a surface to emit thermal
energy by radiation. Different types of surfaces (metals, masonry,
wood, etc.) emit thermal energy through radiation at different
efficiencies. Accordingly, these materials have different emissivity
coefficients which must be considered in order to make accurate
measurements with an infrared thermometer.
Emissivity on the TI290 may be adjusted from 0.01 to 0.99 to enable
accurate measurement of the temperature of most types of materials.
Generally speaking, shiny bright surfaces such as chrome, white
boards, etc. exhibit lower emissivity than flat black materials.
For guidance only, the chart below may be used to estimate
emissivity for many different types of materials. However, the
emissivity of surfaces is dependent upon many parameters such as
surface finish, temperature, shape of the object, etc.
This chart should be used for guidance only.
Material Emissivity
Asphalt 0.93
Red brick 0.93
Gray brick 0.75
Porcelain ceramic 0.92
Fired clay 0.91
Rough concrete 0.94
Cotton cloth 0.77
Smooth glass 0.92 - 0.94
Granite 0.45
Gravel 0.28
Smooth ice 0.97
Smooth white marble 0.56
Black paint 0.96
Hard rubber 0.94
Wood 0.80 - 0.90
Matte copper 0.22
Commercial sheet aluminum 0.09
Cold rolled steel 0.75 - 0.85
Find a comprehensive list of emissivity values in the app's FAQ section
or visit www.kleintools.com/emissivity.
Google Play
™
store is a trademark of Google LLC.
App Store
®
is a registered trademark of Apple Inc.
