PLEASE READ CAREFULLY:
IMPORTANT POINTS OF ATTENTION FROM THE GENERAL INSTALLATION INSTRUCTIONS
ALL FLOORS SHOULD BE INSULATED BEFORE UNDERFLOOR HEATING INSTALLATION.
INSTALLING FLOOR HEATING:
KLIMA CABLE: The connecting cable CANNOT be shortened. The part of the cable with the word **SPLICE*** must be
installed in the floor screed.
Shortening the connecting cable for the KLIMA MAT: The connecting cable may be shortened AT MOST by 3 meters (no
less than 2 meters). All cables that are attached to the mat must be installed in the floor.
Extending connecting cables: The connecting cables can be extended as required. Take however the capacity (Amps) of
the floor heating into account and adjust the capacity of the extension cables accordingly.
FLOOR SENSOR INSTALLATION:
Ensure that the sensor is installed well clear (min. 50 cm) of central heating pipes, water pipes, drains and electrical
wiring. Install the sensor as closely as possible in the middle of 2 loops. Ensure that the heating cables do not make direct
contact with the conduit in which the floor sensor is mounted. The end of the sensor pipe must be closed. Check that the
sensor cable is free to move to the end of the pipe.
Extending the floor sensor: The floor sensor may be extended as required up to a maximum of 10 meters. Use a signal
