Klingenburg CERTO - Commissioning Report; HD-Hose, Tube, Nozzle Checks; Pump Station Commissioning Checks; Controller Commissioning Checks

49
Checklist - Commissioning report
Klingenburg humidifier
Company:
Contact Person:
Phone:
Address:
Customer of the assignment:
Customer Number:
Company:
Contact Person:
Phone:
Address:
The installation site:
Building:
Facility name:
To the plant:
Controller:
KB-Nummer: Construction year:
Done
Observation:
Number of nozzles (nozzle sticks)
Type of nozzles
Complete system flushed
Spray pattern of nozzles checked
Winglets adjusted
Tightness of the nozzle system
1) HD-Hose, Tube, Nozzel tube, Nozzel
yes no
Oil control HD-Pump, Type
Controlled pump drive
Solenoid valves (ND, HD)
Pressure gauge 0 - 16 bar, 0 - 250 bar
Inlet pressure of the pump station
Tightness of the pump station
Drain checked
Pressure switch checked (ND / HD)
Start point
Humidity setpoint
Min. Frequency
Max. Frequency
Power-up time
Power-down time
Rinse interval
Staff on site:
Rinse duration
P boosting
Drying
Level 2 on
Level 2 off
Level 3 on
Level 3 off
2) Pump station
5) Setting values of the controller
7) Personnel
yes no
Checked electrical connections
Communication with the GLT: - Control signal
- Error messages
Controller programmed
Current consumption [A]: Controller:
Motor:
Frequency [Hz]
Pressure [bar]
Frequency Min [Hz]
Operating hours as per display
3) Controller 4) Humidifier data
Shall Be
2. Step
Shall Be
3. Step
Shall Be
6) various
Order number:
Signature:
Name (customer) in print:
Date:
Klingenburg Signature:
L1:
U:
L2:
V:
L3:
W:
Name:
yes no
yes no
