Technical data
Controller type
CERTO-FU 750 CERTO-FU 1500 CERTO-FU 2200 CERTO-FU 4,0 CERTO-FU 5,5
Output kW 0,75 1,5 2,2 4,0 5,5
External fusing
(slow-blow)
16 A 16 A 20 A 20 A 25 A
Supply line 220-240 V 50/60 Hz 380-460 V 50-60 Hz
Ambient temperature 0-40 °C
Protection type IP 54
Output frequency 0-80 Hz
Frequency resolution 0,1 Hz
Control signals 0 - 10 V ; 4 - 20 mA
Capacity
Output relay
250 V AC, 1 A
Power supply cables Generally speaking, shielded cables should be used
Dimensions
W / H / D [mm]
265 / 232 /128 355 / 266 /168 400 / 300 / 290 400 / 300 / 290 400 / 500 / 240
Weight [kg] 3,5 8 13 13 16
Minimum
input pressure
2 bar
Maximum
input pressure
5 bar
Maximum
output pressure
140 bar
Dimensions
Pump station
W:500 H:650 D:540
Weight
Pump station
65 kg 69 kg 73 kg 76 kg 82 kg
Feed water quality Deionised water with conductive value 5 - 20 microsiemens / cm / water hardness < 1°dH
Controller:
Pump station:
Conformity to
standards
VDI 6022, sheets 1, VDI 3803 sheets 1,
Test certificates Hygiene conformity assessment DMT Essen / TÜV Nord / National Institute of Publiic Health
Motorleistung
Anschlusss
-
pannung
Anschluss-
art
Nenn-
Stromstärke
regelbar mit Reglertyp
0,55 kW (230/400V) 3 x 230 V Dreieck I
nenn
3,3 A CERTO FU 750
0,75 kW (230/400V) 3 x 230 V Dreieck I
nenn
3,14 A CERTO FU 750
1,5 kW (230/400V) 3 x 230 V Dreieck I
nenn
6,3 A CERTO FU 1500
2,2 kW (230/400V) 3 x 230 V Dreieck I
nenn
8,52 A CERTO FU 2200
4,0 kW (400/690V) 3 x 400 V Dreieck I
nenn
8,1 A CERTO FU 4,0
5,5 kW (400/690V) 3 x 400 V Dreieck I
nenn
11,75 A CERTO FU 5,5
