·KLINGENBURG
16
SF:00Hz IF:00Hz
01: Excess current (motor / rotor blocked;
short circuit between U, V, W)
05: Overload (Control unit / motor overloaded)
09: Mains undervoltage
14: Earth fault
15: Excessive voltage in network
21: Excessive temperature at the power output
stage, ambient temperature too high; control
unit overloaded
99: Software error
The control unit is again ready for operation as soon as the
trouble has been acknowledged by interruption of the mains
voltage or by simultaneous pushing of the three push-buttons.
Unit is blocked
Motor exc. temp.
Running check
Hardware err:EXX
Attention: Contact with
live elements even after
the power supply has
been cut can be life
threatening. Please
wait 15 minutes!
Troubleshooting
Correct running and operation is shown by the following
display
If, however, the following display is showing
you will have to check the defect according to the following
list.
Hardware err:E01
SF:00Hz IF:00Hz
Trouble shooting for the basic contol unit KR4 / KR 7
- Check fuse / Mains voltage
- Control unit is not enabled (ext. potential free contact closed)
- Check the thermal protective contact
- Connect thermal protective contact at the control Unit.
-
During operation with rotation monitor:
- Check distance of magnetic switch to the rotor
- Check connection of the magnetic switch at the
control Unit
- Check if V belt has come off
- Check V belt tension
During operation without rotation monitor:
- Alter programming of the Control Unit
(See Description of the item rotation monitor)
- Check position of jumper according to the
requirements
- Check if control unit signal is effective
- Check connection control signal at the control unit
on contacts 5, 7 and 9 against ground (contacts 3 or 4)
supply voltage of 24 V must exist.
If not: check trip line
