·KLINGENBURG
15
External operation
After having determined “External operation”, the following
display is shown:
The Control Unit is pre-set to 5%, in spite of this it is possible
that an unwanted running of the rotor could be caused on
account of interference voltages. By increasing this voltage
rate, this can definitively be prevented. Acknowledgement is
carried out by depressing the Enter push-button. The following
display then appears:
In case “Cleaning on” is selected, the value is pre-set to 20
minutes.
The cleaning run is set in a cyclic mode between 40, 60, 80
and 100 minutes. The cleaning run ensures that the rotor
revolves regularly by half a rotation when the control signal is
set to 0 V for a prolonged period of time. The control unit must,
however, be released. By multiple depressing of the selection
loads, the intervals will change. Confirm by depressing the
Enter push-button.
Manual Operation / External Operation
The rotation of the rotor can be supervised by means of the
rotation monitor. In case you have ordered a control unit with
the option rotation monitor, you will select
In case the Control Unit is not equipped with a rotation monitor,
you will select
The ON/OFF switching of the rotation monitor is effected via the
selection push-buttons, the confirmation by means of the Enter
push-button.
During operation correct running is shown by the following
display:
Start point: 05%
Cleaning on
Cleaning off
Clean int 40min
Runcontrol on
Runcontrol off
SF:80Hz IF:80Hz
In order to accept the changes that have been entered at last, it
is necessary to store them.
In order to store the data, depress the “Enter” push-button.
By depressing the selection push-buttons instead of the
“ENTER” push-button, the changes that have been entered at
last are deleted and the previous menu items are active again.
The control unit returns into its normal operation mode.
In the case of manual operation, the display shown is as
follows:
In order to start or to stop the controller in the case of manual
operaton, depress the “ENTER” push-button. Th e se le ct ed
rotational speed is justified.
In the case of external operation, the display shown is as
follows:
Store data?
Stored!
Not stored!
HF: Hz IF: Hz
Runcontrol
SF: Hz IF: Hz
Attention: Contact with
live elements even after
the power supply has
been cut can be life
threatening. Please
wait 15 minutes!
