FIGURE 2
LINE LEVEL CONNECTIONS
LINE IN
R
L/LFE
LR
LINE IN
R
L/LFE
Processor/Pre-Amp/Receiver Processor/Pre-Amp/Receiver
PRE • OUT
LFE OUTPUT
Left and Right pre-outs on Processor/
Pre-Amp/Receiver connected to Left and Right
line inputs on subwoofer amplifier
LFE Output on Processor/Pre-Amp/Receiver
connected to LFE input on suboofer amplifier
OR
