SOUNDBAR PLACEMENT
.25” (6.35mm) .25” (6.35mm)
TV
POSITIONNEMENT DE LA BARRE DE SON • UBICACIÓN DE LA BARRA DE SONIDO • SOUNDBAR-PLATZIERUNG • COLLOCAZIONE DEL SOUNDBAR • POSIÇÃO DA BARRA SONORA • 条形音箱布置
SUBWOOFER PLACEMENT
POSITIONNEMENT DU CAISSON DE GRAVES • UBICACIÓN DEL SUBWOOFER • SUBWOOFER-PLATZIERUNG • COLLOCAZIONE DEL SUBWOOFER • POSIÇÃO DO SUBWOOFER • 低音炮布置
A
A
B
B
TV
TV
TV

Table of Contents

Other manuals for Klipsch R-20B

Preview: Reference
Reference16 pages
Preview: Safety Instructions
Safety Instructions42 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Klipsch R-20B and is the answer not in the manual?

Klipsch R-20B Specifications

General IconGeneral
Audio Channels2
Subwooferincluded
High Resolution Audiono
Dialogue Enhancementno
Number of Drivers4
Video Pass-throughhdr
HDR Formatdolby vision
Tweeters2
Maximum Frequency Response20 kilohertz
Minimum Frequency Response27.5 hertz
Inputshdmi, optical
Outputsnone
HDMI Inputs0
HDMI Outputs0
HDMI ARC Portsyes
HDMI HDCP 2.2 Inputs0
HDMI HDCP 2.2 Outputs0
USB Ports0
Bluetoothyes
Wireless Connectivitybluetooth
Wireless Subwoofer Connectivityno
Wireless Multi-Room Audiono
Optical Audio Inputs1
Remote Controlno
Weight and Dimensions IconWeight and Dimensions
Depth13.1 inches
Height4.1 inches
Width49.4 inches
Net Weight8.5 pounds
Subwoofer Depth16 inches
Subwoofer Height13.125 inches
Subwoofer Width7 inches
Subwoofer Weight24 pounds
