POWER CONNECTION
PREPARATION
PRODUCT SPECIFICATIONS
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, DO NOT attempt to
assemble the product.
Estimated Assembly Time: 45 minutes
Tools Required for Assembly (not included): Sharp knife or utility knife to cut carton, Phillips
screwdriver, athead screwdriver, combination square, framing square, tape measure or ruler,
13 mm open end wrench, 10 mm open end wrench or adjustable wrench, 5 mm Allen wrench.
SPEED AND WIRING
• The no-load speed of this tool is approximately 5,000 RPM. This speed is not constant and
decreases under a load or with lower voltage.
• For voltage, the wiring in a shop is as important as the motor’s horsepower rating. A line intended
only for lights cannot properly carry a power tool motor. Wire that is heavy enough for a short
distance will be too light for a greater distance. A line that can support one power tool may not be
able to support two or three tools.
DOUBLE INSULATION
To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider than the
other). This plug will t in a polarized outlet only one way. If the plug does not t fully in the outlet,
reverse the plug. If it still does not t, contact a qualied electrician to install the proper outlet.
DO NOT change the plug in any way.
Max depth of cut at 90 degrees 3- 1/2 in
Max depth of cut at 45 degrees 2 - 1/2 in
Max rip to right of blade 30 in
Max rip to left of blade 17 in
Net Weight 68 lbs
Input 120 V~, 60hz, 15 Amps
Blade Arbor Hole 5/8 in
Blade Diameter 10 in
No Load Speed 5,000 r/min (RPM)
Blade Max Speed Rating 5,500 r/min (RPM)
Number of Teeth 28
Blade Thickness 0.07” (1.8 mm)
Blade Kerf 0.1” (2.6mm)
BLADE DESCRIPTIONS
APPLICATION DIAMETER TEETH
Construction Saw Blades (thin kerf with anti-stick rim)
General Purpose 10”(254mm) 28/40
Fine Crosscuts 10”(254mm) 60
Woodworking Saw Blades (provide smooth, clean cuts)
Fine crosscuts 10”(254mm) 80
This tool can only be used with woodworking
saw blades.
