To check/adjust (vertically):
1. Place framing square on table and against both blade
(W) and riving knife (X). Blade (W) and riving knife
(X) are aligned if framing square contacts both blade
(W) and riving knife (X) evenly with no gaps.
2. If blade and riving knife are not aligned, using hex head
wrench, slowly turn the bottom set screw (located below
riving knife lock knob) until the riving knife (X) is aligned
with the blade (W).
ADJUSTMENTS
