Kobalt 2644068 - Changing the Spray Tip

13
4. CHANGING THE SPRAY TIP
• Insert any of the spray tips (F1-F5) onto the spray wand (G).
After changing the spray tip, if the angle of the spray tip is not appropriate, adjust the joint between
the gun wand and the triggle handle and tighten it again.
OPERATING INSTRUCTIONS
4
F5
F2
F3
F4
F2
J
F
WARNING
5
